Quick Air Supply Set-Up Tips

• 1.

  Always follow government and company safety instructions, use eye protection and follow User Notes available on this website. Caution: Rotation will start when compressed air is connected to your turbine.

• 2.

  For proper operation, it is essential that clean, dry, oil-free 90 psi / 6.2 bar compressed air at the specified CFM/Liters per Second flow rate is supplied to your turbine. A contaminated air supply will damage your turbine components and result in a repair. Always install a filter/extractor to ensure an impeccably clean air supply. Accessory filters matching your product are available on this site and are included in standard equipment with 600 Series spindles.

• 3.

  Air Turbine Tools® increase airflow on-demand to correspond with cutting load and maintain high speed in the cut. It is therefore important to ensure that the volume of compressed air flow is available at the specified flow rate matching your turbine. Inadequate supply of air pressure or CFM / Liters Per Second flow results in underpower performance, which causes accelerated bearing wear. Please use a flow meter to check your pressure and flow rate.

• 4.

  All hoses, fittings, couplings, and connectors must have the minimum internal diameter specified for your turbine and must not restrict airflow to your turbine. Use 1/4”/ 6mm minimum diameter hose and couplings for all tools, motors, and spindles up to 1/8″/3mm collet capacity.

• 5.

  For our larger and double turbine tools, spindles, and motors, including 210, 230, 310, 450,460, 740XP, 625X, 650, and 660 models, please ensure a minimum 3/8” / 10mm internal diameter on all hoses, fittings, and couplings. This is important to prevent the restriction of airflow and assure full power performance.
